ACT 5e Digital Keypad

By ACT

€120.00

VAT of 23% Included In Price

No Price?? - contact us at gatekits@gmail.com for a great deal

ACT 10

The Digital Keypad ACT 5e  is a simple to use and easy to install standalone access control product. Keypad backlighting enhances functionality at night or in poor light conditions. The ACT 5e access control keypad is contained in a stylish polycarbonate housing, with stainless steel keys and potted electronics, allowing for indoor and outdoor installation. The ACT 5e may be surface or flush mounted on to a standard single gang electrical back box.

Main Features - ACT 5e Digital Keypad

  • pin only digital keypad
  • 10 user codes
  • push to exit input
  • incorrect code lockout
  • toggle mode
  • 5 amp, 30 Volt DC relay
  • polycarbonate housing, stainless steel keys
  • keypad backlighting
  • potted electronics
  • indoor / outdoor (IP67)
  • surface / flush mount options
  • mounts on to standard single gang electrical back box

Product Specification - ACT 5e

  • Operating Voltage: 12 - 24 Volts AC / DC
  • Current Consumption: 30 / 120 mA
  • Operating Temperature: - 10 to + 50 º C
  • Door Open Time: 0 - 255 seconds
  • Relay Contact Rating: 5A / 30 Volt
  • Weight: 225 gms
  • Dimensions (H x W x D, mm): 130 x 94 x 25 (surface); 128 x 94 x 18.5 (flush)
  • Mounting: surface / flush options
  • Installation: indoor / outdoor (IP67)
  • Construction: rugged polycarbonate housing, stainless steel

Installation Guidelines - ACT 5e

  • Require operating voltage of 12 - 24 volts AC or DC
  • 5 amp lock output
  • Indoor / outdoor installation (IP67)
  • Operating Temperature: -10 to +50 C
  • Can be surface or flush mounted
